Ubiquiti NanoStation M2 (NSM2)

Ubiquiti NanoStation M2 (NSM2) is a versatile outdoor 2.4GHz Customer Premises Equipment (CPE) device designed for both access point and client applications. It delivers high performance while remaining cost-effective, making it suitable for a variety of networking needs.

Specifications

• Operation Modes: AP, Client, WDS
• Frequency Range: 2.4 – 2.5 GHz
• Maximum Transmission Speed: 150 Mbps
• Standards: 802.11b/g/n
• Chipset: Atheros
• Max Output Power: 27 dBm
• Sensitivity: -95 dBm (for 1 Mbps)
• Modulation: OFDM
• Encryption: WEP (64/128/152), WPA, WPA2
• LAN Ports: 1 x RJ45 10/100 Mbps
• Default IP: 192.168.1.20
• Default Username/Password: ubnt / ubnt
• Power Supply: 15 V, 0.8 A
• Operating Temperature: -30 to 80 °C
• Dimensions: 294 x 80 x 30 mm
• Processor: MIPS 24KC, 400 MHz
• RAM: 32 MB
• NAND: 8 MB

Key Features

• High Throughput: Capable of maximum speeds up to 150 Mbps, the NanoStation M2 efficiently handles multiple connections simultaneously.
• Flexible Operation Modes: It can function as an access point, client, or in WDS mode, providing flexibility for various network setups.
• Robust Design: Built to withstand outdoor conditions, it features a durable casing and is equipped for pole or wall mounting.
• Integrated Antenna: With a gain of 12 dBi, the integrated antenna provides strong signal strength and extended coverage for reliable connectivity.
• Easy Deployment: Plug-and-play installation makes it user-friendly, allowing for quick setup and integration into existing networks.

Common FAQs

• What are the primary uses for the NanoStation M2?
  It can be used as an access point to serve multiple clients or as a client device to connect to another network.

• What is the maximum speed supported by the NanoStation M2?
  The device can achieve a maximum transmission speed of 150 Mbps.

• Is the NanoStation M2 suitable for outdoor use?
  Yes, it is designed for outdoor deployments and can withstand various weather conditions.
• How does the integrated antenna improve performance?
  The 12 dBi antenna enhances signal strength and extends coverage, ensuring reliable connectivity even at a distance.

• Can the NanoStation M2 be mounted easily?
  Yes, it comes with mounting options for both poles and walls, facilitating easy installation.
