Ubiquiti 16 ports Switch Lite USW-Lite-16-Poe, (8) GbE PoE+ RJ45 ports, (8) GbE RJ45 ports, 45W

Ubiquiti 16 Ports Switch Lite (USW-Lite-16-PoE). This switch features (8) GbE PoE+ RJ45 ports and (8) GbE RJ45 ports, providing a 45W power budget to operate compatible devices such as security cameras, VoIP phones, access points, and more.

Specifications

• Dimensions: 191.7 x 185 x 43.7 mm (7.55 x 7.28 x 1.72 inches)
• Weight: 1.2 kg (2.65 lb)
• Networking Interface: (16) 10/100/1,000 MbE RJ45
• Management Interface: Ethernet In-Band
• PoE Interface: (8) PoE/PoE+ (Pins 1, 2+; 3, 6-)
• Maximum Power Consumption: 15W (excluding PoE output)
• Power Method: Universal AC input (100—240V AC)
• Power Supply: Internal 60W AC/DC power supply
• Supported Voltage Range: 100—240V AC
• Max PoE+ Wattage per Port: 30W
• PoE Budget: 45W
• Operating Temperature: -15 to 40°C (5 to 104°F)
• Operating Humidity: 10% to 90% non-condensing
• Certifications: CE, FCC, IC

LED Indicators

• System:
  • (1) Power: blue/white
  • Flashing white: bootup in progress
  • Flashing blue: firmware upgrading
  • Steady white: factory defaults, awaiting adoption
  • Steady blue: device is adopted
• Ethernet:
  • Green: 1G
  • Amber: 10/100 Mbps
• PoE:
  • Amber: PoE/PoE+

Key Features

• 16 Gigabit Ethernet Ports: Eight ports support 802.3af/at PoE+, delivering up to 30W per port
• 16 Gb/s Switching Capacity: Ensures efficient data handling across connected devices
• Fanless Design: Operates silently, ideal for home offices or business environments
• Managed Switch: Utilize the UniFi Network Controller for comprehensive configuration, control, and monitoring
• Total Non-Blocking Line Rate: 16 Gbps for optimized network traffic

Common FAQs

• What is the maximum power output per port for PoE devices?
  Each PoE+ port can deliver up to 30W of power, supporting a wide range of PoE-enabled devices

• Can I use this switch without PoE?
  Yes, the USW-Lite-16-PoE can function as a regular Gigabit switch without connecting PoE devices

• How do I manage the switch?
  The switch can be managed through the UniFi Network application, allowing you to configure settings, monitor network performance, and update firmware remotely

• Is this switch suitable for outdoor use?
  No, the USW-Lite-16-PoE is designed for indoor use. For outdoor applications, consider Ubiquiti’s outdoor-rated switches

• What kind of devices can I connect to this switch?
  You can connect a variety of devices, including IP cameras, wireless access points, VoIP phones, and standard Ethernet devices

• Does the switch support VLANs?
  Yes, the USW-Lite-16-PoE supports VLAN configuration, allowing you to segment your network for better management and security
