Secolink Universal communicator GSV5 Alarm GSM/GPRS Kit

Secolink Universal communicator GSV5 Alarm GSM/GPRS Kit

Secolink Universal communicator GSV5 Alarm GSM/GPRS Kit is designed to be used in objects along with other manufacturers intruder alarms systems. It gives options to report to the receiver of CMS, to control and monitor the system with the mobile app SECOLINK PRO (set on TCP/IP or SMS communication), with simple SMS messages or with phone call.

Features: GSV5
Description: Versatile GSM/GPRS communicator
Product type: Alarm system module
In-built wired zones on board: 6
On-Board (open collector type) PGM: 2
Reporting to CMS format: CID by GPRS
Reporting protocols for CMS: E2 (Enigma), FIBRO (Sur-gard), CSV (Patriot), SIA
Compatibility with control panels via KEYBUS: PC5xx, PC14xx, PC15xx, PC16xx, PC18xx
Compatibility with control panels via SERIAL: SP4xxx, SP6xxx, SP7xxx, EVOxxx
Compatible with SG-SYSTEM II , III IP card: Yes
Alarm message for end user: SECOLINK PRO app, GSM call, SMS
Available language for voice guide: English (available other languages)
Available language for SMS: English (available other languages)
DTMF converting from PSTN to GPRS: Yes (one way)
Available in plastic enclosure: Yes
Maximum current into -PGM1: -0.05 A
Maximum current into -PGM2: -0.05 A
Power supply from an independent source of power
Maximum battery charging current: +0.035 A
Rated voltage of power supply (AC): ~20 V
Minimum AC voltage: ~16 V
Maximum AC voltage (Note: higher than ~22 V voltage can damage control panel): ~22 V
Maximum current of slow blowing fuse used in primary AC: 250 mA
Maximum AC power consumption: 15 mA
Power supply from an Control Panel source of power:
Power supply (DC): 9 – 14 V
Current consumption: 50 mA
Current consumption with all PGM’s: 260 mA
Overall dimensions W x H in mm: 120 x 64
Environmental compliance: ROHS
Operating temperature: From -10oC to +50oC
Interface for communicator settings programming: USB
Interface for communicator firmware updating: USB
