Invt Three Phase 5.5Kw hybrid Inverter

A frequency Converter is a kind of power converter that adopts the Sensor-less vector technique and changes the running speed of the AC asynchronous motor by controlling the output voltage and frequency. It can exactly detect the three-phase output AC signal and the change of phase-angle just by the current sensor and correct the frequency automatically by the computing mode of sensor-less vector, to ensure the motor fixed speed when the load changes.
The built-in parameter auto-tuning function, can automatically identify the characteristic of the motor and set up related parameters, making the motor run continually steadily even when the operating parameter of the motor changes as times go by.
Protection function in all fields: protection of under-voltage, over-voltage, over-current, prevention of motor stall, over-load, and over-heat.
Control function special for industrial mechanic:6 kinds of multifunction programmable digital input function (99 kinds of functions are optional); 3 kinds of multifunction programmable digital output function (94 kinds of function are optional); Timer and counter, Rotation speed trace function, flip-flop function, Automatic operating function. One or more frequency converters can be dynamically controlled by one computer at the same time, besides that, one computer may simultaneously control nearly 99 sets of converters (Relay amplifier must be installed when the numbers of converters exceed 31 units ); Built-in PID function. The range of output frequency is 0.00-650.00Hz.
Adopts a low inductance structure, reduces the peak voltage of a circuit, strengthens the EMC function, and improves the reliability of the product greatly.

Product Specs

Package includes:

• 1 x Inverter 5.5KW
• English user manual

1. Output Power:5.5kw

2.Rated current:13A

2. Rated Frequency:50hz/60hz

3. Output Frequency Range:0~650Hz

4. Input Voltage Range:3 phase  380V±15%

5. Output Voltage Range:3 phase 380V±15%

6.Control way: Open-loop vector control(SVC)      V/F control

7. Starting Torque: G type machine:0.5Hz/150%( SVC)

8. Main function: Control and adjust the speed of the ac motor
