Bixolon XD5-40T thermal Printer

Bixolon XD5-40T is a 4-inch Thermal Transfer Desktop Label Printer designed for a wide range of barcode and labeling applications.

With its compact, durable clamshell design, this mid-level label printer offers high performance and flexibility, making it ideal for businesses in Manufacturing, Logistics, Retail, and Healthcare.

This XD5-40T is equipped with a suite of advanced features, including field-installable Peeler, Auto Cutter, and external paper supply, providing ease of use and quick configuration.

It supports both Thermal Transfer and Direct Thermal printing methods and is compatible with a variety of label media types, making it a versatile and reliable choice for your labeling needs.

Specifications

• Print Method: Thermal Transfer, Direct Thermal
• Print Speed: Up to 6 inches per second (152 mm/sec)
• Print Resolution: 203 dpi
• Print Width: Up to 108 mm
• Print Length: Up to 1,000 mm
• Sensor:
  • Transmissive (Fixed)
  • Reflective (Adjustable)
  • Head Open
• Ribbon Type: Wax, Wax/Resin, Resin (Outside)
• Ribbon Width: 33 ~ 110 mm
• Ribbon Length: Up to 300 m
• Interface: USB, USB Host (with Twin Function™ for settings duplication)
• Optional Features:
  • Peeler (Field-installable)
  • Auto Cutter (Field-installable)
  • External Paper Supply
• Dimensions: Compact and easy-to-fit design for any work environment

Features

• Print Speed: Prints at speeds up to 6 inches per second (152 mm/sec), making it suitable for both high-volume and time-sensitive applications.
• Print Resolution: Offers a 203 dpi resolution, ensuring clear text and barcodes for easy scanning and readability.
• Print Method: Supports both Thermal Transfer (for durable labels) and Direct Thermal (for cost-effective and short-term labels).
• Media Handling:
  • Print Width: Up to 108 mm for large-format labels.
  • Print Length: Prints labels up to 1,000 mm in length, allowing for flexible labeling options.
  • Sensor: Features Transmissive (Fixed) and Reflective (Adjustable) sensors for accurate media detection.
• Ribbon Compatibility: Works with Wax, Wax/Resin, and Resin ribbons, suitable for a variety of media types.
  • Ribbon Width: 33 ~ 110 mm
  • Ribbon Length: Up to 300 m.
• Tool-Free Features:
  • Peeler and Auto Cutter can be installed without tools, providing added convenience and flexibility for your workflow.
  • External Paper Supply option allows for greater media capacity and fewer roll changes.
• USB Host Port: Features a USB Host Port, which allows you to duplicate existing printer settings and data from one printer to another using Twin Function™.
• Programming Languages: The printer is compatible with industry-standard programming languages such as SLCS™, BPL-Z™, and BPL-E™, ensuring seamless integration with various software and systems.
• Compact & Durable Design: The clamshell design makes it easy to load media and maintain the printer, while the durable construction ensures it withstands the demands of high-volume environments.

Applications

Bixolon XD5-40T is designed to support a wide range of label printing needs, making it suitable for:

• Manufacturing: Labeling parts, products, and containers for inventory and production tracking.
• Logistics & Warehousing: Shipping labels, pallet labels, and barcode tracking for inventory management.
• Retail: Price tags, barcode labels, and product identification.
• Healthcare: Patient identification labels, specimen tracking, and medical product labeling.
